Docol 500DP Dual Phase Steel (DP)
Docol 500DP: Docol 500DP dual-phase steel has good formability and weldability and is suitable for automotive safety components such as reinforcements. This steel is subjected to a special heat treatment, which mainly produces a two-phase structure. Ferrite, which can impart formability, represents one phase, while martensite, which is responsible for strength, represents the other phase.
Excellent quality and reliable performance.
Reasonable price and high cost-effectiveness.
Adequate inventory and timely supply.
Complete specifications to meet diverse needs.
Strict quality inspection to ensure quality.
Professional team, attentive service.
+8615966663192
+8615966663192
Product Parameters

Docol 500DP: Docol 500DP dual-phase steel has good formability and weldability and is suitable for automotive safety components such as reinforcements. This steel is subjected to a special heat treatment, which mainly produces a two-phase structure. Ferrite, which can impart formability, represents one phase, while martensite, which is responsible for strength, represents the other phase. Bainite may also be present as a complementary phase.



Mechanical Properties

Steel GradeStandardPlatingTest DirectionYield Strength Rp0.2 (MPa)Tensile Strength Rm (MPa)Extension Rate A80( min%)Minimum Bend Inner Diameter for 90 ° Bend
Docol CR290Y490T-DPVDA239- 100:2016UC, GI, GA*, FRL290-380490-60024UC 0.0xtGI, GA, FI0.5xt
Docol CR230Y500T- DLSSABUCT230-300500-600240.0xt
Docol CR290Y500T- DPSSABUCT290-370500-600200.0xt



Chemical Composition

Steel GradePlatingC (max %)Si (max %)Mn(max %)P (max %)S(max %)Al( %)Cr Mo(max%)B(max %)Nb Title(max %)
Docol CR290Y490T-DPUC0.100.501.000.0250.0100.015--0.10-
Docol CR290Y490T-DPGI,GA,ZA0.140.501.800.0500.0100.015-1.01.000.150.005
Docol CR230Y500T- DLUC0.080.401.800.0250.0100.015--0.10-
Docol CR290Y500T- DPUC0.100.501.000.0250.0100.015--0.10-



Plating

Plating TypePlating GradeStandardSingle-sided coating quality, single-point test (g/m2)Single side thickness, for reference only(μm)
GI40/40VDA239-10040-605.6-8.5
GI50/50VDA239-10050-707.0-9.9
GI60/60VDA239-10060-908.5-12.7
GI70/70VDA239-10070-1009.9-14.1
GI85/85VDA239-10085-11512.0-16.2
GI115/115VDA239-100115-15516.2-21.8
GA40/40VDA239-10040-605.6-8.5
GA50/50VDA239-10050-807.0-11.3
ZA95As required
7-
ZA130As required
10-
